Quality Tools
Quality Tools and MicroLab overview:
https://www.komaxgroup.com/quality-tools-overview
Quality ToolsACD
The ACD incision monitoring system automatically detects the smallest contact between the blade and conductor strands for flawless crimp results and the highest requirements.
Quality ToolsQ1250 scalable
As a basic version, the scalable Q1250 module offers testing of the stripping as well as the crimp and seal. All quality features are comprehensively tested in the full package.
Quality ToolsMicroHeight 10
The MicroHeight 10 crimp height measurement device verifies the quality of crimps either as a stand-alone device or integrated into certain Komax machines for quality verification.
Quality ToolsMicroForce 85
The MicroForce 85 crimp monitoring device minimizes faulty crimps, contributes to process optimization using data analysis and ensures traceability in production.
Quality ToolsQpLite
The QpLite is a simple and mobile crimp force monitoring device that captures quality based on crimp force curves on tabletop crimpers.
Quality ToolsQpLite 2
The QpLite2 is a scalable crimp force monitoring device (CFM) ensuring the quality of each crimp. It can be integrated with either single or double-channel benchtop crimp presses.
Quality ToolsMicroLab 10
The MicroLab 10 is a compact micrograph laboratory in a case system that measures and evaluates small quantities of B crimps in the 0.5 - 2.5mm processing range.
Quality ToolsMicroLab 11
The MicroLab 11 is a portable all-in-one micrograph laboratory solution with integrated automatic cutting and semi-automatic grinding functions.
Quality ToolsMicroLab 20
The MicroLab 20 is a fast and reliable micrograph laboratory solution for quick analysis on wires ranging from 0.05 mm² to 80 mm², with customizable reporting options.
Quality ToolsMicroLab 30
The MicroLab 30 mobile micrograph laboratory creates micrographs for medium to large quantities of B-crimps, MIL-crimps and hex-crimps with a diameter of 0.5 to 10.0 mm.
Quality ToolsMicroLab 45
The MicroLab 45 is the best micrograph labratory for high level quality checks. With the fully automatic transport system, it quickly meassures and evaluates micrograph pictures.
Quality ToolsMicroLab 55
The MicroLab 55 is a stand-alone micrograph laboratory for all types of crimping available on the market for both cross sections and longitudinal sections with a width of 0.5 to 30.0 mm.
Quality ToolsQ2205
As a module in a wire processing machine, the Q2205 measurement device measures with a defined pull-out speed of 25 or 50mm/min the pull-out forces of 20 to 500 N.
Quality ToolsQ1210
The Q1210 precision measuring module for wire processing machines measures pull-out forces of 20 to 1000 N with a pull-out speed of up to 200mm / min.
Quality ToolsMicroPull 10
The MicroPull 10 is a standalone measurement system that measures pull-out forces ranging from 20 to 1000 N. It offers a variety of different pull-off speeds of up to 100 mm/min.
Quality ToolsQstat-100
The Qstat-100 motorized pull-out force measurement device checks and visualizes the pull-out profile as a transportable table-top device to check the wire harness quality.
Quality ToolsQstat Pro
The Qstat Pro is a motorized bench top Pull Tester. It also serves as a quality inspection station for wire harness production on the shop-floor level.
Quality ToolsKomax 341
The Komax 341 crimp height measurement device measures terminals up to a height of 8 mm and compares them with the target crimp height. If there is no match, production will not start.
Quality ToolsQ1140
The Q1140 high-voltage spark tester for fully automatic wire processing machines checks wire insulation for the smallest needle holes and microscopic cracks.
Quality ToolsKomax 345
The high-quality, digital Komax 345 microscope enables the control of stripping and crimping quality, even with miniature terminals and the smallest wire cross sections.
Quality ToolsCPA Pro
With the CPA PRO crimp force monitoring, a quick and accurate check of the performance of fully automatic wire processing machines is carried out– without an additional PC.
Quality ToolsCrimp Module Analyzer
The Crimp Module Analyzer quality measuring device is used to measure and check the stability of the crimp module in μm using a two-stage force simulator.
Quality ToolsCFAlab
The CFA-Lab PC software evaluates the CFA/CFA+ crimp force monitoring data from crimping machines and modules. Optimizing the settings minimizes rejects.
Quality ToolsCPA+
The CPA+ crimp force monitoring is the compact quality control and maintenance device for crimp modules– with integrated graphic display for analysis in real time.
Quality ToolsSL Starlite
The SL Starlight crimp force measurement module with large LCD display offers flexible process monitoring for various fully automatic wire processing machines.
Quality ToolsSmartOptic
The SmartOptic image acquisition module offers high-quality color images and can be operated independently of the micrograph laboratory in conjunction with SmartVision on a PC.
Quality ToolsVS45
The VS45 fuse box detection system utilizes AI identification and font library technology to effectively eliminate errors caused by manufacturing process tolerances.
