Harness Manufacturing

Fully automatic housing assembly and wire harness production will become increasingly important in the future. This is because the highest level of quality and efficiency is only achieved by automatically executing these processes with integrated monitoring systems. The new generation of loaders represents a quantum leap in fully automatic wire harness production.

Harness ManufacturingZeta 620
The Zeta 620 assembly machine provides wires on two process models fully equipped for control cabinet construction – including labeling and terminals.
Harness ManufacturingZeta 630
The Zeta 630 increases productivity in control cabinet construction with two process modules from batch size 1 and with up to 36 different wires in the wire changer.
Harness ManufacturingZeta 640
Thanks to their five (Zeta 640) or eight (Zeta 650) process modules, Zeta 640/650 can process up to 36 wires without changeover, from batch size 1 and just-in-time.
Harness ManufacturingZeta 650
Thanks to their five (Zeta 640) or eight (Zeta 650) process modules, Zeta 640/650 can process up to 36 wires without changeover, from batch size 1 and just-in-time.
Harness ManufacturingOmega 740
The Omega 740/750 wire assembly machine can be used to produce wire harnesses of various complexity and to equip them with terminal housings on one or both sides.
Harness ManufacturingOmega 745
In contrast to Omega 740/750, the Omega 745/755 machines are also equipped with a fully automatic conveyor system for depositing the wire harnesses.
Harness ManufacturingOmega 750
The Omega 740/750 wire assembly machine can be used to produce wire harnesses of various complexity and to equip them with terminal housings on one or both sides.
3 Variants available
Harness ManufacturingOmega 750 SA
The Omega 750 SA cable assembly machine produces wire harnesses of varying degrees of complexity and allows for terminal housings to be loaded on one side or both sides.
Harness ManufacturingOmega 755
In contrast to Omega 740/750 series, the Omega 745/755 machines are also equipped with a fully automatic conveyor system for depositing the wire harnesses.
Harness ManufacturingOmega 840
The Omega 840 / 850 wire assembly machine automatically produces wire harnesses with individual wires with cross-sections of 0.13 –2.5 mm² as well as twisted wires.
Harness ManufacturingOmega 850
The Omega 840 / 850 wire assembly machine automatically produces wire harnesses with individual wires with cross-sections of 0.13 –2.5 mm² as well as twisted wires.
Harness ManufacturingEasyWiring
EasyWiring is a cutting-edge interactive harness assembly board. This innovative solution is designed to streamline the production and prototyping of electrical harnesses.
